Sheet Metal Joint Levelling Machine | HOPEX 1250
The metal leveling machine removes coil set from hot-rolled strip, while the sheet leveling machine handles thinner blanks. A sheet metal leveling machine with nine rollers suits general workshops. The steel leveling machine flattens heavy plate before shearing, cutting downstream scrap. Pair each unit with a feeder and stacker for a complete line.
1250Sheet leveling machine
Detail
1250Metal leveling machine
|
No.
|
1250sheet leveling machine
|
|
|
1
|
Product name | 1250sheet metal leveling machine |
|
2
|
Equipment footprint | 2500*1600*1750mm |
|
3
|
Feed width | widest 1250mm |
|
4
|
Feed thickness | 0.5-3.0mm |
|
5
|
Material of raw materials | color coated coil |
|
6
|
Online punching, production speed | 0-15 meters/minute. |
|
7
|
Number of Rows | 5mm top, 6mm bottom |
|
8
|
Main Motor Power | 7.5kw+11kw |
|
9
|
Voltage | 380v 50HZ |
Q: 1. How do I adjust the machine for different widths and heights?
For standard lines, it can be adjusted via high-precision manual spacers. However, for our premium series (like the HOPEXcustomized lines), we integrate an automatic motorized width-adjustment system controlled entirely through the PLC touchscreen, moving the forming rollers smoothly to your desired dimensions within seconds.
Q: 2. Is the width adjustment manual or fully automatic via PLC?
We offer both options based on your budget. Our advanced cable tray and housing profile lines feature fully automatic PLC one-key changeover. The operator simply inputs the parameters on the screen, and the machine adjusts itself automatically, eliminating human error.
3. How long does a standard size/profile changeover take?
With our traditional manual adjustment lines, it takes about 1-2 hours. With our upgraded Smart PLC One-Key Changeover System, a complete width adjustment (e.g., from 100mm to 600mm for cable trays) takes less than 2 minutes, drastically reducing your downtime and boosting factory productivity.
