HOPEX-Anti Seismic Bracket
Seismic components are inspected. Buyers of an anti seismic bracket roll forming machine are usually supplying into projects where the bracing has to be traceable, so the paperwork around the machine matters as much as the machine.
| Document | Status | Purpose |
|---|---|---|
| Machinery test report | Provided | Records the factory test of the assembled line |
| Video outgoing-inspection | Provided | Visual record of the line running before dispatch |
| Operation manual | Provided | Setting, running and changeover procedures |
| Maintenance schedule | Provided | Lubrication points and inspection intervals |
Because tooling is Cr12 with 40Cr shafts, section dimensions do not drift gradually through a production run. That is what allows a single first-article approval to represent the whole batch.
Punching is performed in line, so hole position is a machine setting rather than a site operation subject to individual workmanship.
The Cr12MoV blade produces a consistent cut edge, which matters where brace ends are inspected or welded.
| Item | Parameter |
|---|---|
| Feeding width | 135 / 157 / 177 / 197 mm |
| Rolling thickness | 1.5 – 2.5 mm |
| Roll forming speed | 10 – 15 m/min |
| Drive model | Gearbox and arch frame |
| Roller material | Cr12 |
| Roller shaft material | 40Cr |
| Blade material | Cr12MoV |
| Total power | 69 KW |
| Voltage | 380 V |
| Weight | 20000 kg |
| Package size | 2600 × 300 × 200 cm |
| Place of origin | Tianjin, China |
| Lead time, 1 set | 75 days |
| Lead time, 2 – 5 sets | 90 days |
Warranty period is 2 years from delivery.
Q1. What inspection documents come with the machine?
A machinery test report and a video outgoing-inspection record, both provided as standard.
Q2. Can we witness the test before shipment?
The video outgoing-inspection is recorded and supplied; further arrangements can be discussed with our engineers.
Q3. Which components are covered by the warranty?
Pressure vessel, motor, bearing, gearbox, engine, pump and gear, for 2 years.
Q4. How does the machine support our own quality records?
Consistent section geometry and in-line hole position mean a first-article approval represents the batch.
Q5. What are the recorded machine parameters?
135 / 157 / 177 / 197 mm feeding widths, 1.5 – 2.5 mm thickness, 10 – 15 m/min forming speed, 69 KW at 380 V.
Q6. Where is the machine manufactured?
Tianjin, China.
