50-400cable tray making machine
Workshop-friendly cable tray bending machine and cable tray cutting machine give accurate bends and clean, burr-free cuts. The compact design fits small shops making trench cable tray and custom lengths. Setup is easy, and upkeep is low. Optional stands and blade sets are available. Strong steel body ensures long service life
50-400 Perforated cable tray roll forming machine
Detail
50-400 Galvanized cable tray making machine
|
No.
|
50-400Cable tray punching machine
|
|
|
1
|
Input material width | 150–850 mm |
|
2
|
Input material thickness | 0.7 (±0.03)–2.0 (±0.03) mm |
|
3
|
Input material type | Q235B cold-rolled strip steel, hot-rolled strip steel, galvanized sheet. |
|
4
|
In-line punching; production speed | 8–16 m/min |
|
5
|
Equipment footprint | 30 × 2.5 × 2.2 m (L × W × H) |
|
6
|
Material feed direction | Left-in, right-out |
|
7
|
Voltage specifications | 400V ±5%, 60Hz, 3-phase |
|
8
|
Total installed power capacity | Approx. 50 kW |
Q: 1. How do I adjust the machine for different widths and heights?
For standard lines, it can be adjusted via high-precision manual spacers. However, for our premium series (like the HOPEXcustomized lines), we integrate an automatic motorized width-adjustment system controlled entirely through the PLC touchscreen, moving the forming rollers smoothly to your desired dimensions within seconds.
Q: 2. Is the width adjustment manual or fully automatic via PLC?
We offer both options based on your budget. Our advanced cable tray and housing profile lines feature fully automatic PLC one-key changeover. The operator simply inputs the parameters on the screen, and the machine adjusts itself automatically, eliminating human error.
3. How long does a standard size/profile changeover take?
With our traditional manual adjustment lines, it takes about 1-2 hours. With our upgraded Smart PLC One-Key Changeover System, a complete width adjustment (e.g., from 100mm to 600mm for cable trays) takes less than 2 minutes, drastically reducing your downtime and boosting factory productivity.
